WD Ultrastar DC HC330
Enterprise Data Centre HDD
Economical mid-capacity enterprise hard drives delivering fast, reliable data access for traditional data centre applications. 10TB, 7,200 RPM, SATA or SAS rated for 550TB/year workloads with a 5-year warranty.
- 10TB capacity up to industry-leading air-platform density
- 7,200 RPM with up to 273 MB/s sustained transfer rate
- SATA 6Gb/s and SAS 12Gb/s interface variants available
- 256MB cache + Flash-based Non-Volatile Cache (NVC)
- 550 TB/year workload rating for Tier 2 data centre use
- 2nd Gen Dual-Stage Microactuator for precision head positioning
- Secure Erase (SE) and SED + TCG Enterprise SSC options
- 2 Million Hour MTBF · 0.44% AFR · 5-Year Warranty
HC330 Model Options
Available in SATA and SAS interfaces with standard Secure Erase or full SED encryption choose the right variant for your environment.
| SKU | Interface | Security |
|---|---|---|
| 0B42266 Standard | SATA 6Gb/s | SE (Secure Erase) |
| 0B42270 | SATA 6Gb/s | SED + TCG Enterprise SSC |
| 0B42258 | SAS 12Gb/s | SE (Secure Erase) |
| 0B42262 | SAS 12Gb/s | SED + TCG Enterprise SSC |
Economical. Reliable. Enterprise-Ready.
The HC330 targets Tier 2 data centre applications where access speed, total cost of acquisition and proven reliability matter most.
Lower Total Cost of Acquisition
Air-filled platform keeps acquisition costs lower than helium drives while delivering enterprise-class access density (IOPs/TB).
2nd Gen Dual-Stage Actuator
Enhanced head-positioning accuracy for better drive performance reducing read/write errors at high track pitch densities.
Flash Non-Volatile Cache
NVC on both SATA and SAS models improves write performance by providing a fast staging area for incoming writes.
550 TB/Year Workload Rating
Designed for Tier 2 data centres handles demanding enterprise workloads including block, file and distributed storage.
Secure Erase & SED Options
Secure Erase (SE) wipes all data before drive disposal. SED with TCG Enterprise SSC adds full hardware encryption at rest.
2M Hour MTBF Reliability
0.44% AFR and 2 million hour MTBF backed by a 5-year Western Digital warranty for peace of mind.
CMR Technology
Conventional Magnetic Recording ensures full compatibility with all RAID levels and enterprise storage applications.
Wide Application Support
Storage arrays, rack-mounted enclosures, distributed computing, block storage and file storage architectures.
Legacy System Compatible
Standard SATA 6Gb/s and SAS 12Gb/s interfaces with 512e format drop-in compatible with existing infrastructure.
Full Specifications
| Capacity | 4TB · 6TB · 8TB · 10TB |
| Form Factor | 3.5 Inch |
| Interface | SATA 6Gb/s · SAS 12Gb/s |
| Spindle Speed | 7,200 RPM |
| Cache | 256 MB |
| Sector Format | Advanced Format 512e / 4Kn |
| Max Transfer Rate | Up to 273 MB/s |
| Workload Rating | 550 TB/year |
| MTBF | 2 Million Hours |
| AFR | 0.44% |
| Recording Method | CMR (Conventional Magnetic Recording) |
| Actuator | 2nd Gen Dual-Stage Microactuator |
| NVC Cache | Flash-based Non-Volatile Cache (SATA & SAS) |
| Platform | Air-Filled (CMR, cost-efficient) |
| Security Options | Secure Erase (SE) · SED + TCG Enterprise SSC |
| Operating Temp | 0°C to 60°C |
| Power (Active) | ~6.8W typical |
| Warranty | 5 Years |
Where HC330 Fits Best
Traditional Storage Arrays
Rack-mounted SATA/SAS RAID arrays requiring reliable, high-access-density storage.
Distributed Storage
Scalable computing environments including block and file storage architectures.
Enterprise Backup
Cost-effective Tier 2 backup target for primary data with high workload tolerance.
On-Prem Data Centres
Traditional on-premise deployments needing proven air-platform reliability and economics.
